TecArt LEDrive CV 6 DIN Rail 0-10V

LEDrive CV Hybrid 4X is a desktop stand alone controller for constant voltage LEDs. High PWM frequency (31.5 KHz) makes it flicker free and film and TV compatible. The unit is controlled via two potentiometers, which allows you to control the brightness and colour temperature of the LEDs. It features different modes and built-in effects. The unit has a PL7 locking connector and driving capacity of 24A.

LEDrive CV Hybrid 4X can be supplied with an external 12 – 36VDC power supply.

FEATURES
• Potentiometer control.
• External power supply 12 – 36VDC.
• PL7 locking connector output.
• 1 multicoloured indication LED.
• Overdrive mode and fire effect included.

SPECIFICATIONS
• Input voltage: 10 – 36VDC.
• Power supply: External.
• Dimensions: 160mm (L) x 100mm (W) x 40mm (H).
• Mounting method: Desktop.
• Outputs: 2 channels.
• Driving capacity: Up to 24A.
• Output voltage: Equal to input voltage – stabilised voltage (PWM).
• Temperature: 0 – 40 degrees Celsius.

LEDrive CC 6 DIN Rail is a constant current LED dimmer, utilising DMX/RDM. It features advanced 16 bit dimming technology, allowing different dimming curves to be set. The unit is flicker free and film and TV compatible. Standalone speed-adjustable fade effects can be triggered by RDM. The unit has 6 channels of output, for use with up to 1200mA LEDs.

RDM compliant device “ANSI/ESTA E1.20 Entertainment Technology – Remote Device Management over USITT DMX512”.

RDM or Remote Device Management is a protocol enhancement to DMX512 that allows bi-directional communications between light fixtures and lighting consoles or RDM specific software over a standard DMX line.

LEDrive CC 6 DIN Rail can be supplied with an external 12 – 48VDC power supply.

FEATURES
• DMX-512 input and output.
• External power supply 12 – 48VDC.
• Terminal strip output.
• 2 main indication LEDs.
• Operating modes:
1. Pre-programmed lighting scenes: Choose from several pre-programmed scenes via RDM.
2. Control of the channels via DMX.

SPECIFICATIONS
• Input voltage: 10 – 48VDC.
• Power supply: External.
• Dimensions: 110mm (L) x 90mm (W) x 60mm (H).
• Mounting method: DIN Rail.
• DMX working mode: 6 channels.
• DMX signal input: Terminal strip/RJ45.
• DMX signal output: Terminal strip/RJ45.
• Outputs: 6 channels.
• Addressing: Via RDM.
• Driving capacity: Up to 1200mA per channel.
• Temperature: 0 – 40 degrees Celsius.

LEDrive CV 6 DIN Rail is a constant voltage LED dimmer, utilising DMX/RDM control. It features advanced 16 bit dimming technology, allowing different dimming curves to be set. High PWM frequency (10 KHz) makes it flicker free and film and TV compatible. Standalone speed-adjustable fade effects can be triggered by RDM. The unit has 6 channels of output, each with 2A fuse protection.

RDM compliant device “ANSI/ESTA E1.20 Entertainment Technology – Remote Device Management over USITT DMX512”.

RDM or Remote Device Management is a protocol enhancement to DMX512 that allows bi-directional communications between light fixtures and lighting consoles or RDM specific software over a standard DMX line.

LEDrive CV 6 DIN Rail can be supplied with an external 12 – 36VDC power supply.

FEATURES
• DMX-512 input and output.
• External power supply 12 – 36VDC.
• Terminal strip output.
• 2 main indication LEDs.
• Operating modes:
1. Pre-programmed lighting scenes: Choose from several pre-programmed scenes via RDM.
2. Control of the channels via DMX.
