TecArt LEDrive CC 12 Wall Mount (320W) 0-10V

LEDrive CC 12 Rack Mount is a constant current LED dimmer, utilising 0-10V analogue control. The unit is flicker free and film and TV compatible. The unit has 12 channels of output, for use with up to 2500mA LEDs. It has a built-in 320W power supply.

FEATURES
• 0-10V control input.
• Internal power supply 48VDC 320W.
• Terminal strip or RJ45 output.
• 1 main indication LED.

SPECIFICATIONS
• Input voltage: 100 – 240VAC.
• Power supply: Internal 320W. Can be used with external power supply.
• Dimensions: 483 (W) x 240 (D) x 88 (H).
• Mounting method: Rack Mount.
• Control input: Terminal strip.
• Outputs: 12 channels.
• Driving capacity: Up to 2500mA per channel, with combined total of 320W across all channels using the built-in power supply.
• Temperature: 0 – 40 degrees Celsius.

LEDrive CV 24 Rack Mount is a constant voltage LED dimmer, utilising DMX/RDM control. It features advanced 16 bit dimming technology, allowing different dimming curves to be set. High PWM frequency (10 KHz) makes it flicker free and film and TV compatible. Standalone speed-adjustable fade effects can be triggered by the onboard switches or RDM. The unit has 24 channels of output, each with 5A fuse protection. It has a built-in 640W power supply.

RDM compliant device “ANSI/ESTA E1.20 Entertainment Technology – Remote Device Management over USITT DMX512”.

RDM or Remote Device Management is a protocol enhancement to DMX512 that allows bi-directional communications between light fixtures and lighting consoles or RDM specific software over a standard DMX line.

FEATURES
• DMX-512 input and output.
• 2 x internal power supply 12/24VDC 320W.
• Terminal strip output.
• 2 main indication LEDs.

SPECIFICATIONS
• Input voltage: 100 – 240VAC.
• Power supply: Internal 2 x 320W. Can be used with external power supply.
• Dimensions: 483 (W) x 370 (D) x 88 (H).
• Mounting method: Rack Mount.
• DMX working mode: 24 channels.
• DMX signal input: XLR or RJ45.
• DMX signal output: XLR or RJ45.
• Outputs: 24 channels.
• Addressing: Via onboard switches or RDM.
• Driving capacity: Up to 5A per channel, with combined total of 640W across all channels using the built-in power supply.
• Output voltage: Equal to input voltage – stabilised voltage (PWM).
• Temperature: 0 – 40 degrees Celsius.

LEDrive CV Hybrid 4X is a desktop stand alone controller for constant voltage LEDs. High PWM frequency (31.5 KHz) makes it flicker free and film and TV compatible. The unit is controlled via two potentiometers, which allows you to control the brightness and colour temperature of the LEDs. It features different modes and built-in effects. The unit has a PL7 locking connector and driving capacity of 24A.

LEDrive CV Hybrid 4X can be supplied with an external 12 – 36VDC power supply.

FEATURES
• Potentiometer control.
• External power supply 12 – 36VDC.
• PL7 locking connector output.
• 1 multicoloured indication LED.
• Overdrive mode and fire effect included.

SPECIFICATIONS
• Input voltage: 10 – 36VDC.
• Power supply: External.
• Dimensions: 160mm (L) x 100mm (W) x 40mm (H).
• Mounting method: Desktop.
• Outputs: 2 channels.
• Driving capacity: Up to 24A.
• Output voltage: Equal to input voltage – stabilised voltage (PWM).
• Temperature: 0 – 40 degrees Celsius.
