TecArt LEDrive CC 12 Rack Mount (320W) 0-10V
LEDrive CC 12 Rack Mount is a constant current LED dimmer, utilising 0-10V analogue control. The unit is flicker free and film and TV compatible. The unit has 12 channels of output, for use with up to 2500mA LEDs. It has a built-in 320W power supply.
FEATURES
• 0-10V control input.
• Internal power supply 48VDC 320W.
• Terminal strip or RJ45 output.
• 1 main indication LED.
SPECIFICATIONS
• Input voltage: 100 – 240VAC.
• Power supply: Internal 320W. Can be used with external power supply.
• Dimensions: 483 (W) x 240 (D) x 88 (H).
• Mounting method: Rack Mount.
• Control input: Terminal strip.
• Outputs: 12 channels.
• Driving capacity: Up to 2500mA per channel, with combined total of 320W across all channels using the built-in power supply.
• Temperature: 0 – 40 degrees Celsius.
Related products
-
LED drivers
TecArt LEDrive CV 24 Wall Mount (2x320W) DMX/RDM
