Miller CompassX CX2 Fluid Head Only
Compassx 2 is an exceptional ball levelling fluid head designed for “on the go” creative professionals needing a versatile and affordable solution with uncompromised performance. Whether you shoot with a mirrorless camera, DSLR, mid-sized cine-rig or an ENG camera, CX2 is capable of balancing payloads from 0kg to 8kg. It features advanced precision fluid drag, intuitive controls, and fast set-up.
The CX2 employs CB PlusTM technology providing 16 positions of counterbalance and, with 3+0 settings of Miller’s unrivalled fluid drag coupled with 60mm of camera plate travel, you can easily select the perfect set-up to match your configuration for ultimate camera control.
Constructed of lightweight high-strength die-cast alloy and tough composite polymers and featuring precision ball bearings Miller have combined robust engineering with silk smooth pan and tilt camera movements. Built for extreme conditions the CX2 performs consistently over a wide range of temperatures and environments giving you confidence when out on a shoot.
Versatile and light weight, CX2 makes a great choice for applications such as news gathering, documentary, wildlife and filmmaking. The CX2 meets the demands for reliability and “THE RIGHT FEEL” that are hallmarks of Miller, enabling you to tell your story.
$1,543.00
Specification – CX2 Fluid Head
| Payload Range | 0-8.0kg (0-17.6lbs) |
| Weight | 2.3kg (5.1lbs) |
| Counterbalance Positions | 16 selectable positions (15+0) |
| Pan Tilt Drag | 3 selectable fluid drag positions + 0 |
| Pan Tilt Locks | Positive lock calliper brake system |
| Tilt Range | + 90°/ -75 |
| Pan Range | 360° |
| Camera Platform | Quick release, side load camera plate |
| Sliding Range | 60mm (2.4″) |
| Mounting Base | Ø75mm (2.9”) ball levelling |
| Height Above Bowl | 167mm (6.6″) |
| Illuminated Controls | Bubble level |
| Pan Handle | Fixed length 390mm (15.4″) |
| Temperature Range | -40° to +65°C (-40° to +149°F) |
| Brand |
|---|
