Chauvet DJ Vivid Drive 23N LED Video Panel Driver

Chauvet DJ

Chauvet DJ Vivid Drive 23N
The Chauvet DJ Vivid Drive 23N is a video driver with numerous input/output options for any Novastar video panel. It’s built-in video scaler allows for quick resizing of all video content. The Vivid Drive 23N has an on-board digital display that easily sets all settings including transitions, content, scale, aspect ratio, PiP and more. Seamlessly transition between different inputs with multiple transition effects. The HDMI loop out allows easy system expansion and connection to additional drivers or monitors. A convenient rackmount holds up to 2 drivers or can be removed for tabletop use.

$2,399.00

Features:
Video driver with numerous input/output options for any Novastar video panel
Built-in video scaler allows for quick resizing of all video content
HDMI loop out to expand system and connect to additional drivers or monitors
Convenient rackmount holds up to 2 drivers or can be removed for tabletop use
On-board digital display easily sets all settings including transitions, content, scale, aspect ratio, PiP, etc
Seamlessly transition between different inputs with multiple transition effects

Specifications:
Control Protocol: Novastar
Control Input Connectors: RS-232, USB
Video Input Connectors: BNC, VGA, HDMI (w/ loop out)
Video Output Connector: HDMI, DVI, RJ45 (x2)
Max. Supported LEDs: 1,310,720
Max. Supported Panels (Vivid 4): 30 per RJ45
Included Rackmount: 1U
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 40 W, 0.2 A @ 230 V, 50 Hz
Weight: 1.4 kg
Size: (w/o rackmount) 219 x 250 x 45 mm
Approvals: CE

SKU: CDJ-VIVID-DRIVE23N Category: Brand:
