Data and DMX distribution

Chauvet DJ DMX-AN2 ArtNET DMX Node

Chauvet DJ DMX-AN2
The Chauvet DJ DMX-AN2 is a multi-purpose Art-Net/sACN node that converts 1 Ethernet cable to 2 DMX universes. Its optical and electrical isolation is ready for any situation and the durable Neutrik® etherCON® in/through port ensures reliability. The built-in web-based GUI means no universe/subnet setup. DMX-AN2 automatically redirects the web page if the IP address is changed. The unit supports Power over Ethernet (POE) or an external power supply. Both outputs can be set to either Art-Net or sACN and DMX-AN2 functions as an Art-Net to DMX or DMX to Art-Net interface. Onboard LED indicators quickly inform status and the integrated mounting bracket is included to quickly install into any location.

$319.00

Description

Features:
New: Automatically redirects the web page if the IP address is changed
New: Optical and electrical isolation is ready for any situation
Multi-purpose Art-Net/sACN node converts 1 Ethernet cable to 2 DMX universes
No universe/subnet setup with the built-in web based GUI
Durable Neutrik® etherCON® in/through port ensures reliability
Supports Power over Ethernet (POE) or an external power supply
Both outputs can be set to either Art-Net or sACN
Functions as an Art-Net to DMX or DMX to Art-Net interface
Onboard LED indicators quickly inform status
Integrated mounting bracket to quickly install into any location

Specifications:
DMX Channels: 1024
DMX Connectors: 3- pin XLR
Input Voltage: (DC): 9 VDC, 500 mA (external power supply: 100 to 240 VAC, 50/60 Hz)
(POE): 48V 0.4 A
Weight: 0.2 kg
Size: 120 x 64 x 39 mm
Approvals: CE
Control Protocol: Art-Net, DMX, sACN
Art-Net Version: 3
