Event Lighting

• Light Source: 12 x 20W RGBWA+UV 6 in 1 LED
• Beam Angle: 22° (Optional: 8°, 15°, 45°)
• Output: 12,700 lux @ 2.0m full on
• PWM: 1,240Hz
• LED Life: 50,000 hours

Effects

• Dimming: 5 x 16-bit Dimming Curves
• Strobe: 1~30Hz

Power

• Input Voltage: 100V~240V AC, 50/60Hz, 250W
• Power Connection: True1 in/out

Control

• Operational Modes: DMX, WDMX, auto run, sound active, master/slave, manual colour control, static colour control
• Display: 4-button LCD control panel
• DMX Protocol: DMX512
• DMX Channel Mode: 1 / 2 / 3 / 4W / 4A / 6 / 8 / 12 / 14
• DMX Interface: 5-pin XLR in/out

Housing

• Housing Materials: Die-cast aluminium, matte black finish
• Cooling: Fanless Cooling
• IP Rating: IP65
• Dimension: 299 x 217 x 333mm
• Net Weight: 3.2kg
• Rigging: 1 x Omega bracket with 1/4 turn quick locks

• Light Source: 12x 8W RGBW 4-in-1 LEDs
• Beam Angle: 40°
• LED Lifespan: 50,000 hours

• PAR9X12BH-IP Outdoor Battery Par Can
• 9x 12W RGBWAU LEDs
• Die-cast aluminium housing
• 25° beam angle
• WDMX onboard
• IR control capability
• IP65 rating for outdoor use
• 100V~240V AC input voltage
• 72W power consumption
• Seetronic® Outdoor True1 power connection
• Battery operating time: 16 hours (one colour mode), 8 hours (colour fading mode)
• DMX control with manual, auto, sound active, and master/slave modes
• Wireless DMX compatibility
• OLED touch display with glass buttons
• DMX512 and Wireless DMX (W-DMX) control protocols
• 6 or 10 DMX channels
• Seetronic® 5 Pin Outdoor DMX in/out interface
• Fanless cooling system
• Matte black finish die-cast aluminium housing
• Accessories included: 1M Seetronic® Outdoor Powercon, 1M Seetronic® Outdoor DMX Cable, IR Remote Controller
• Road case (PAR9X12OBC) available for charging and transport, fits 6 units

• Light source: 3 x 4W RGBW
• Operation Modes: DMX, auto, manual, sound active, master/slave, IR remote
• Control Interface: 3-pin XLR in/out, IR remote
